Features:

This machine is developed for filling materials that are difficult to automatically measure, such as solid shaped or amorphous materials. The filling material is manually placed in the upper measuring tray and then automatically filled, sealed, and packaged by the machine. This machine is most suitable for small batch and multi variety production packaging.

Main packaging uses:

Ginger slices, pickles, beef jerky, chocolate beans, dehydrated broccoli, peanut kernels and other types of nuts can be packaged with this machine.

Technical parameters:

Filling material: particles, amorphous solids

Packaging form: Three sided sealing

Bag making length: 70mm-150mm (hot roller needs to be replaced when the length changes)

Bag width: 40mm-90mm (the molding machine needs to be replaced when the width changes)

Packaging capacity: 20-60 bags per minute (actual filling and packaging speed may vary depending on product size, raw material properties, etc.)

Filling capacity: 1-30cc (The measurement range of filling capacity varies depending on the properties of the raw materials and the feeding device.)

Electricity usage: 3-phase 380V 3KW

Dimensions (with screw filling device): 800mL x 1300mm (W) x 1500mm (H)

Host weight: approximately 550kg
